Wet Pillar Ground Fire Hydrant DN150

Wet Pillar Ground Fire Hydrant DN150

Technical Requirement

1.The products shall be manufactured and accepted in accordance with the standards
2.Products should be in accordance with the standard method, after passing the test can be ex factory, water pressure seal test pressure1.6 MPA, water pressure strength test pressure 2.4 MPA
3.Outer Coating C04-42 red alkyd Enamel, color should be smooth and uniform,no cracks,scratches and bruises, the inner surface coating F53-1 Red Salvianolic anti-rust paint
4.In the picture trademark, the writing and so on mark should be accurate, clear

Caractéristiques

1.Fully maintainable.
2.Ductile iron construction.
3.2½” London round thread outlet to BS 750.
4.Universal drilled inlet flange BS Standard
5.Low weight design. Material ：Ductile Iron

Test

1.Hydraulic test to BS 750
2.Seat: 1.1 x PN. Body: 1.5 x PN. Operating torque test

Pression de service

Pression de service maximale 16 bar (230psi)

Temperature Range

0 °C à 80 °C

Material Specification
